Kohler V-Twin Command Pro 27 HP 747cc 1-1/8" x 3-5/16" #CV750-3005 (CV752-3000)
HomeStore

Kohler V-Twin Command Pro 27 HP 747cc 1-1/8" x 3-5/16" #CV750-3005 (CV752-3000)

Kohler V-Twin Command Pro 27 HP 747cc 1-1/8" x 3-5/16" #CV750-3005 (CV752-3000)

$3,199.00
Kohler V-Twin Command Pro 27 HP 747cc 1-1/8" x 3-5/16" #CV750-3005 (CV752-3000)—
$3,199.00

The Story

27 hp Command Pro
1-1/8" x 3-5/16" shaft, tapped 7/16" with 1/4" keyway.
OHV, cast iron cylinder liners,
full pressure lube w/ oil filter,
electric start w/ 20amp alternator,
less gas tank.
Heavy duty canister air cleaner system,
special chopper grass screen and fixed guard.
2 year warranty.
Model CV750-3005.
110 lbs

This 27 HP peak performer features a vertical shaft and air cooling in a v-twin configuration. Its a 4-cycle, gasoline-powered engine with cast iron cylinder liners, aluminum block construction, and an overhead valve design.
Easy Dependable Starts
  • Two-barrel carburetor
  • Electronic ignition system
  • Solenoid shift starter
Reliability & Long-life Design
  • Hardened crankshaft journals
  • PTO sleeve bearing (side load)
  • High-efficiency fan and screen
  • Large heavy-duty air cleaner system
  • Oil cooler
  • Cast iron cylinder liners
  • Hydraulic valve lifters
  • Full-pressure lubrication
  • Spin-on, full-flow oil filter
Peak Power Performance
  • High-performance spark plugs
  • 20 amp charging, regulated
  • Larger in-line fuel filter
  • Overhead valve (OHV) design
Quiet, Smooth Operation
  • Engineered material blower housing
  • CARB & EPA emission-certified
User-friendly Maintenance
  • Extended maintenance intervals
  • Yellow oil fill cap/dipstick handle
  • Dual oil drains
  • Easy-access oil fill/dipstick
  • Two-year limited warranty
Specifications
Shaft: Vertical
Cylinders: V-Twin
Cooling: Air
Engine Type: 4-cycle, gasoline, OHV, cast iron cylinder liners, aluminum block
MODEL
Command PRO CV750
MAX. POWER @ 3600 RPM hp (kW)
27 (22.4)
DISPLACEMENT cu. in. (cc)
45 (747)
BORE in. (mm)
3.3 (83)
STROKE in. (mm)
2.7 (69)
PEAK TORQUE @ MAXIMUM lbs. ft. (Nm)
47.1 (63.8) @ 2600
COMPRESSION RATIO
9.4:1
DRY WEIGHT lbs. (kg)
105 (47)
OIL CAPACITY U.S. quarts (liters)
2.0 (1.9)
LUBRICATION
Full pressure w/full-flow filter
DIMENSIONS L x W x H in.
20.5 x 17.7 x 22.5
*Length is blower housing to air cleaner. Width is spark plug to spark plug. Height is top of air cleaner cover to mounting feet.
